OmniScan 360 Industrial Vision System

360° Vision, Zero Blind Spots

Overview

The OmniScan 360 Industrial Vision System is a challenging, multi-camera inspection tool that can take high-quality panoramic pictures in real time in tough industrial settings. It has 360° visual coverage, superior IMU-based picture stabilization, and real-time video stitching, which makes it better than regular handheld inspection equipment. The approach makes data clearer, speeds up operations, and makes them safer in difficult situations like high-vibration zones, robotic arms, and inspections done by drones.

Business Challenges

High vibrations, blind spots owing to restricted FOV, operator fatigue from manual repositioning, and fragmented, non-stitched data reduced industrial inspection efficiency, accuracy, and safety in critical situations.

  • Extreme Vibration-Induced Motion Blur: Consistent EIS/OIS didn't work well with high-frequency vibrations.
  • Limited Field of View: Single-camera systems caused blind spots and disjointed footage.
  • Manual Operation Fatigue: Recurring repositioning improved inspection time and operator strain.
  • Fragmented Data: Not being able to give stitched, real-time, panoramic footage for full context.

Silicon Signals’ Solution

A 360° multi-camera vision system featuring IMU stabilization, GPU stitching, and real-time pipelines.

IMU-Based Image Stabilization

ADIS16488 IMU + Linux IIO driver with EKF filters enables <50 ms EIS using DSP/GPU acceleration.

Multi-Camera Stitching

Four synced 12MP global shutter cameras stitch real-time panoramas with GPU-accelerated pipeline.

Custom GStreamer Pipeline

Unified real-time pipeline handles ISP, stitching, and 4K H.265 RTP streaming in a single flow.

System Optimization

Hybrid DSP/GPU/CPU with DVFS delivers modular software design and 8+ hours of efficient battery use.

Company Facts

Vision systems, sensor fusion, and embedded solutions for demanding industries are Silicon Signals' expertise.

Lower Operational Costs
0 %
Improved Productivity
0 %
Better Data Accuracy
0 %

The right solution starts with the right conversation.

Where Goals Become Results

Book your Strategy Call

Tech Stack

Hardware

Qualcomm Snapdragon 888 SoC, Sony IMX392 sensors, Analog Devices ADIS16488 IMU

Software

Embedded Linux (Yocto), Linux Kernel 5.10 (PREEMPT_RT), Custom IIO + ISP drivers

Middleware

GStreamer, OpenCL, RPMsg (where applicable), OpenCV (for calibration/stitching logic)

Connectivity

Wi-Fi 6, Bluetooth 5.2, optional 5G/LTE

Key Benefits

Fatigue-free operation, sturdy stability, and smooth 4K panoramic video enabled 40% quicker examinations.

  • Data Quality: 95% less RMS pixel deviation; less than 0.2-pixel stitch error; no seams or ghosting apparent
  • Efficiency: 30 frames per second of real-time 4K panoramic video; less than 150 milliseconds of total latency; inspection time cut by more than 40%
  • Usability: immersive live view; hands-free use on drones and robotics; operators don't get tired
  • Robustness: IP67-rated, MIL-STD-810G certified; steadfast in heavy vibration, poor lighting, and restricted areas

Download the case study here!

    Best Practices

    Key Best Practices in Designing Industrial 360° Imaging Systems for Stability, Efficiency, and Reliability.

    • Sensor Fusion Must Be Real-Time: DSP offload and exact clock sync are very important when there is industrial vibration.
    • Camera synchronization is a must: For stitching without artifacts, hardware must be in sync with sub-ms accuracy.
    • Balancing Latency vs. Accuracy: Hybrid filtering lets you stabilize things quickly without losing the ability to rectify long-term drift.
    • GPU/DSP Workload Tuning: Profiling and isolating the EIS and stitching pipelines make sure that the work is done in real time.
